Pipes
Stainless Steel Seamless Pipes are pipes made from a single piece of metal with no joint welds. They provide superior strength and durability in comparison to standard welded pipes, making them ideal for use in high-pressure applications. Stainless steel seamless pipes have excellent corrosion resistance due to their chromium content, as well as being able to handle extreme temperatures due to their nickel content. Additionally, these pipes are extremely easy to install and require minimal maintenance.
This type of pipe is well-suited for industries that utilize corrosive media such as chemicals or steam and need reliable piping solutions that can withstand high pressures without fail. These pipes are also widely used in water delivery systems, firefighting equipment, oil refineries, automotive and aerospace industries, as well as many other commercial and industrial applications.
Stainless Steel Seamless Pipes provide excellent strength, corrosion resistance, and temperature resistance, making them the ideal choice for any application that requires reliable pipe solutions. With a range of sizes available and superior durability, these pipes are the perfect solution to your piping needs.
Specifications
ASTM A312,ASTM A249,ASTM A269
Range
6NB to 1200NB
Outer Diameter
1/8" NPS to 12" NPS
Thickness
50 mm to 6000 mm Long
Schedules
SCH. 5, 10, 20, 30, 40, 60, 80, 100, 120, 140, 160, XXS
End
Plain End, Beveled End
Type | Sizes in milimeter | Sizes in inches | Tolerance |
Peeled and Polished | 40.00 - 150.00 | 1.50 - 6.00 | h11, h11-DIN 1013 |
Cold Drawn and Polish | 3.00 to 75.00 | 1/8 to3.00 | h8 to h11 |
Cold Drawn and Ground | 10.00 to 75.00 | 5/6 to 2.50 | h8 to h11 |
Peeled nd Ground | 20.00 - 50.00 | 3/4 - 2.00 | h9 to h11 |
301 | 1.4310 |
304 | 1.4301 |
304L | 1.4307 |
201 | 1.4372 |
316 | 1.4401 |
316L | 1.4404 |
409 | 1.4512 |
430 | 1.4016 |
434 | 1.4113 |
439 | 1.4510 |
Nominal Bore |
Outside | Schedule 5S | Schedule 10S | Schedule 40S | Schedule 80S | Schedule 160S | Schedule XXS | |||||||
Chart | Diameter | |||||||||||||
inches | (O.D) | Wt | Wt | Wt | Wt | Wt | Wt | |||||||
mm | mm | Weight | Weight | Weight | Weight | Weight | Weight | |||||||
mm | (Kg. | mm | (Kg. | mm | (Kg. | mm | (Kg. | mm | (Kg. | mm | (Kg. | |||
/mt) | /mt) | /mt) | /mt) | /mt) | /mt) | |||||||||
3 | 1/8 | 10.3 | 1.24 | 00.276 | 1.24 | 00.28 | 1.73 | 00.37 | 2.41 | 00.47 | - | - | - | - |
6 | 1/4 | 13.7 | 00.390 | 1.65 | 00.49 | 2.24 | 00.631 | 3.02 | 00.80 | - | - | - | - | |
10 | 3/8 | 17.1 | 1.24 | 00.490 | 1.65 | 00.63 | 2.31 | 00.845 | 3.20 | 1.10 | - | - | - | - |
15 | 1/2 | 21.3 | 1.65 | 00.800 | 2.11 | 1.00 | 2.77 | 1.27 | 3.75 | 1.62 | 4.75 | 1.94 | 7.47 | 2.55 |
20 | 3/4 | 26.7 | 1.65 | 1.03 | 2.11 | 1.28 | 2.87 | 1.68 | 3.91 | 2.20 | 5.54 | 2.89 | 7.82 | 3.63 |
25 | 1 | 33.4 | 1.65 | 1.30 | 2.77 | 2.09 | 3.38 | 2.50 | 4.55 | 3.24 | 6.35 | 4.24 | 9.09 | 5.45 |
32 | 11/4 | 42.2 | 1.65 | 1.65 | 2.77 | 2.70 | 3.56 | 3.38 | 4.85 | 4.47 | 6.35 | 5.61 | 9.70 | 7.77 |
40 | 11/2 | 48.3 | 1.65 | 1.91 | 2.77 | 3.11 | 3.68 | 4.05 | 5.08 | 5.41 | 7.14 | 7.25 | 10.16 | 9.54 |
50 | 2 | 60.3 | 1.65 | 2.40 | 2.77 | 3.93 | 3.91 | 5.44 | 5.54 | 7.48 | 8.74 | 11.1 | 11.07 | 13.44 |
65 | 2 1/2 | 73.00 | 2.11 | 3.69 | 3.05 | 5.26 | 5.16 | 8.63 | 7.01 | 11.4 | 9.53 | 14.9 | 14.2 | 20.39 |
80 | 3 | 88.9 | 2.11 | 4.51 | 3.05 | 6.45 | 5.49 | 11.30 | 7.62 | 15.2 | 11.1 | 21.3 | 15.24 | 27.65 |
100 | 4 | 114.3 | 2.11 | 5.84 | 3.05 | 8.36 | 6.02 | 16.07 | 8.56 | 22.3 | 13.49 | 33.54 | 17.12 | 41.03 |
125 | 5 | 141.3 | 2.77 | 9.47 | 3.40 | 11.57 | 6.55 | 21.8 | 9.53 | 31.97 | 15.88 | 49.11 | 19.05 | 57.43 |
150 | 6 | 168.3 | 2.77 | 11.32 | 3.40 | 13.84 | 7.11 | 28.3 | 10.97 | 42.7 | 18.2 | 67.56 | 21.95 | 79.22 |
200 | 8 | 219.1 | 2.77 | 14.79 | 3.76 | 19.96 | 8.18 | 42.6 | 12.7 | 64.6 | 23.0 | 111.2 | 22.23 | 107.8 |
250 | 10 | 273.1 | 3.40 | 22.63 | 4.19 | 27.78 | 9.27 | 60.5 | 12.7 | 96.0 | 28.6 | 172.4 | 25.40 | 155.15 |
300 | 12 | 323.9 | 3.96 | 31.25 | 4.57 | 36.00 | 9.52 | 73.88 | 12.7 | 132.0 | 33.32 | 238.76 | 25.40 | 186.97 |
350 | 14 | 355.6 | 3.96 | 34.36 | 4.78 | 41.3 | 11.13 | 94.59 | 19.05 | 158.08 | 35.71 | 281.70 | - | - |
400 | 16 | 406.4 | 4.19 | 41.56 | 4.78 | 47.29 | 12.7 | 123.30 | 21.41 | 203.33 | 40.46 | 365.11 | - | - |
450 | 18 | 457.2 | 4.19 | 46.80 | 4.78 | 53.42 | 14.27 | 155.80 | 23.8 | 254.36 | 45.71 | 466.40 | - | - |
500 | 20 | 508.0 | 4.78 | 59.25 | 5.54 | 68.71 | 15.09 | 183.42 | 26.19 | 311.2 | 49.99 | 564.68 | - | - |
600 | 24 | 609.6 | 5.54 | 82.47 | 6.35 | 94.45 | 17.48 | 255.41 | 30.96 | 442.08 | 59.54 | 808.22 |
